Screen engraving · BRC series · rotary

Blue Rotary UV Laser Engraver

The larger rotary machine of the two, in three screen sizes to 3500 mm. It takes repeats from 400 to 2500 mm, runs sixteen laser channels as standard with twenty-four available, and reaches 1440 dpi — the one to specify where the designs are fine and the repeats unusual.

Enquire about the BRC series

Specification

BRC2500, BRC3000 and BRC3500

Model	BRC2500	BRC3000	BRC3500
Screen size	2500 mm	3000 mm	3500 mm
Dimension	3950 × 750 × 1220 mm	4450 × 750 × 1220 mm	4950 × 750 × 1220 mm
Net weight	1000 kg	1100 kg	1200 kg
Repeat	640 mm standard · 400 – 2500 mm optional
Resolution	360 / 720 dpi standard · 508 / 1016 / 1440 dpi optional
Laser channels	16 standard · 24 optional
Repeat accuracy	±0.02 mm
Imaging light source	405 nm laser diode
Engraving	6 – 8 min/m at 16 channels, 640 mm repeat
Acceptable file format	BMP / TIFF
Interface	USB
Ambient temperature	8 – 28 °C
Ambient humidity	30 – 50%, non-condensing
Lighting	Yellow light
Power	1.5 kW / 220 V, 50 Hz

What is in the machine

German reducer, with laser, bearings and servo motors from Japan.
Self-developed multi-accuracy lens, for full-bottom halftone and ultrafine lines.
DOSUN’s patented laser constant-temperature technology, with water cooling or semiconductor smart cooling available.
Automatic optical power balancing — laser intensity is set and the channels evened out, which holds exposure efficiency and extends diode life.
No film, ink or wax anywhere in the process.

What we do around it

We specify the machine from the screens your printing line runs, clear it through Egyptian customs ourselves, and install and commission it on your floor. Our technicians are on call afterwards, and we hold the fast-moving parts in Cairo.

Note the ambient requirement: this machine wants 8 – 28 °C and 30 – 50% humidity under yellow light. Worth checking against your room before ordering.
